| Hardware specifications |
| Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3z, IEEE 802.1p, IEEE 802.1q, IEEE 802.1w, IEEE 802.1d, IEEE 802.3af, IEEE 802.3at |
| LED indicators | 1 Link/Ack LED indicator for each port
1 PoE Max LED indicator for each device
1 Power LED indicator for each device
1 SYS LED indicator for each device |
| Interfaces | 24 x 10/100/1000 Base-T Ethernet ports (Data/Power)
2 x 100/1000 Base-X SFP ports |
| Port Lightning Protection | ≥6KV |
| Forwarding mode | Store-and-forward |
| Switching capability | 48 Gbps |
| Packet forwarding rate | 35.7 Mpps |
| MAC address table | 8K |
| PoE Power Supply | Ports 1 to 16 support 802.3af/at standard
1 2 4 5 +, 3 6 7 8 - |
| Input voltage | 100-240V～ 50/60Hz |
| Dimensions(L*W*H) | 440 mm * 284 mm * 44 mm |
| Whole Switch Power Consumption | Whole switch power consumption: <410W;
Maximum PoE output power: 370W |
| Operating environment | Operating temperature: 0°C - 45℃
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%)RH, non-condensing
Storage humidity: (5% - 90%)RH, non-condensing |
| Software specifications |
| PoE Power Supply Management | Port PoE configuration and power supply priority configuration supported
PoE over-temperature protection supported
Smart graphical management and PoE-powered device detection supported
(port status, power assignment, and PoE-powered device status) |
| Security Features | MAC address binding supported |
| VLAN | IEEE 802.1Q VLAN supported |
| Port aggregation | Static aggregation supported
Dynamic aggregation supported |
| Spanning tree | IEEE 802.1w RSTP (Rapid Spanning Tree Protocol) supported |
| Port Mirroring | N: 1 port mirroring supported |
| QoS | FIFO (First-In, First-Out) supported
SP (Strict Priority) supported
WP (Weighted Priority) supported |
| Loading & Upgrade | HTTP upgrade supported
Configuration import and export supported |
| Cloud management | Supports configuration delivery from IMS cloud platform
Supports log reporting and fault detection
Supports remote maintenance: reboot, backup, upgrade |
| Local visualization management | Supports router, switch, AP, IP camera discovery
Supports automatic generation of topology
Supports online/offline status detection for devices
Supports remotely rebooting the IP camera |
| Certificates | CCC, FCC, CE, RoHS |
