| Hardware specifications |
| Network standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3z, IEEE 802.3x, IEEE 802.1p, IEEE 802.1q, IEEE 802.1w and IEEE 802.1d |
| LED indicators | One Link/Act LED indicator for each port
One Power LED indicator
One SYS LED indicator |
| Fixed ports | 8 x 10/100/1000Base-T Ethernet port
2 x 1000Base-X SFP slot |
| Lightning protection | Port: 6 kV
Power supply: 6 kV |
| Forwarding mode | Store-and-forward |
| Switching capacity | 20 Gbps |
| Packet forwarding rate | 14.9 Mpps |
| Switching buffer | 2 Mbit |
| MAC address table | 16K |
| Input voltage | 100 - 240V AC 50/60Hz |
| Dimensions (L x W x H) | 294 mm * 179.6 mm * 44 mm |
| Environment | Operating temperature: 0°C - 45°C
Operating humidity: (10% - 90%)RH, non-condensing
Storage temperature: -40°C - 70°C
Storage humidity: (5% - 90%)RH, non-condensing |
| Certificates | CCC, FCC, CE, RoHS |
| Software features |
| Security features | MAC address binding supported |
| VLAN | IEEE 802.1Q VLAN supported |
| DHCP | Support DHCP client |
| Port aggregation | Static aggregation supported
Dynamic aggregation supported |
| STP | IEEE 802.1w RSTP (Rapid Spanning Tree Protocol) supported |
| Port mirroring | N: 1 port mirroring supported |
| QoS | FIFO (First-In, First-Out) supported
SP (Strict Priority) supported
WP (Weighted Priority) supported |
| Loading and upgrade | HTTP upgrade supported
Configuration import and export supported |
| Cloud management | Supports configuration delivery from IMS cloud platform
Supports log reporting and fault detection
Supports remote maintenance: reboot, backup, upgrade |
| Local visualization management | Supports router, switch, AP, IP camera discovery
Supports automatic generation of topology
Supports online/offline status detection for devices
Supports remotely rebooting the IP camera |
